EN-26 T104 Series Indicators
4.3 Setup Menu
Enter this menu to set scale parameters. Default settings are in bold.
Menu Sub-Menu
Sub-Menu (in
segment)
Options Options (in segment)
Setup
Reset
no, yes
Capacity Unit
kg, lb
/
Range
Single, Dual
,
>|1|< Capacity 0.1-99999.9
/
>|1|< Graduation 0.0001~100
/
>|2|< Capacity 0.1-99999.9
/
>|2|< Graduation 0.0001~100
/
Power On Zero Off, On
,
Power On Unit
Auto, g, kg, lb, oz, lb:oz, t
Auto Tare
Off, On, Accept
, ,
End
/
/
Note: / refers to not applicable in the table above.
Reset [ ]
Reset the Setup menu to factory defaults.
= do not reset
= reset
Capacity Unit [ ]
Select the unit used for calibration.
kg
lb
Range
[ ]
Selects the number of weighing intervals.
This terminal can be configured to use single or dual interval. Each interval can be assigned its own
graduation. If dual interval is selected, the graduation will change when the weight reaches the second
interval.
When Single interval is selected, the additional parameters available are:
Capacity
Graduation
When Dual interval is selected, the terminal functions with two intervals, each with its own capacity and
graduation. In addition to the Interval 1 capacity and graduation parameters, the following two parameters
are available:
Capacity 2
Graduation 2
Capacity
[ ] /
Capacity1
[ ]
Set the capacity of the scale or the first capacity of the scale.
0.1-99999.9
Grad
[ ] /
Grad1
[ ]
Set the scale readability or the first readability of the scale.
0.0001~100
Capacity2
[ ]
Set the second capacity of the scale.
