T104 Series Indicators EN-37
7. TECHNICAL DATA
7.1 Specifications
Equipment Ratings:
Indoor use only
Altitude: 2,000m
Operating temperature: -10°C to 40°C
Humidity:
Maximum relative humidity 80% for temperatures up to 31 °C decreasing linearly
to 50% relative humidity at 40°C.
Electrical supply: 100 - 240V , 0.5A, 50/60Hz
Voltage fluctuations: Mains supply voltage fluctuations up to ±10% of the nominal voltage.
Overvoltage category
(Installation category):
II
Pollution degree: 2
Model T104P
Construction ABS plastic housing, powder coated carbon steel bracket
Maximum displayed resolution 1:30,000
Maximum approved resolution 1:6,000
Weighing units
Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric
Tonne)
Modes Weighing, Counting, Check, Totalization
Display 45 mm / 1.8 in digit height LCD display with 4-color backlight
Check undicator 3 color (red, green, yellow) bar
Keyboard 4 button membrane keyboard
Auto-zero tracking Off, 0.5 d, 1 d or 3 d
Load cell excitation voltage 5VDC
Load cell drive Up to 6 X 350 ohm
Load cell input sensitivity Up to 3 mV/V
Stabilization time 1 second
Power
6 VDC rechargeable battery;
100-240 VAC / 50-60 Hz internal power supply
Battery life
Rechargeable battery: up to 100 hours continuous use with
backlight off
Interface RS232 standard, Optional USB device or Ethernet
Shipping dimensions
300 x 265 x 135 mm
11.8 x 10.4 x 5.3 in
Product dimensions (with bracket)
252 x 176 x 80 mm / 9.9 x 6.9 x 3.1 in
Approx. net weight 1.3 kg / 2.9 lb
Approx. shipping weight 1.6 kg / 3.5 lb
Operating temperature range -10°C to 40°C / 14°F to 104°F
