EN-38 T104 Series Indicators
Model T104S
Construction 304 stainless steel housing, 304 stainless steel bracket
Protection IP66
Maximum displayed resolution 1:30,000
Maximum approved resolution 1:6,000
Weighing units
Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric
Tonne)
Modes Weighing, Counting, Check, Totalization
Display 45 mm / 1.8 in digit height LCD display with 4-color backlight
Check indicator 3 color (red, green, yellow) bar
Keyboard 4 button membrane keyboard
Auto-zero tracking Off, 0.5 d, 1 d or 3 d
Load cell excitation voltage 5VDC
Load cell drive Up to 6 X 350 ohm
Load cell input sensitivity Up to 3 mV/V
Stabilization time 1 second
Power
6 VDC rechargeable battery;
100-240 VAC / 50-60 Hz internal power supply
Battery life Up to 100 hours continuous use with backlight off
Interface RS232 standard, Optional USB device or Ethernet
Shipping dimensions
300 x 265 x 135 mm
11.8 x 10.4 x 5.3 in
Product dimensions (with bracket)
260 x 204 x 74 mm / 10.2 x 8.0 x 2.9 in
Approx. net weight 3.1 kg / 6.8 lb
Approx. shipping weight 3.4 kg / 7.5 lb
Operating temperature range -10°C to 40°C / 14°F to 104°F
