BÜCHI Labortechnik AG Installation | 5
Operation Manual FatExtractor E-500 37/88
u Put the sealing on the bottom of the con-
denser.
u Attach the solvent connection nut with the seal
to the condenser.
u Connect the solvent collector tube.
NOTICE!Do not use force to carry out this ac-
tion step.
u Put the condenser in the condenser rack.
