14 | Appendix BÜCHI Labortechnik AG
82/88 Operation Manual FatExtractor E-500
14.1.2 Solvent collector schematic
Solvent collector
Solvent collector
Solvent collector
Solvent collector
Solvent collector
Solvent collector
Exhaust
Tank pump
Connection
Tank OUT solvent
Connection
Tank IN
Condenser
solvent tank
IN (solvent)
Condenser
solvent tank
OUT
Fig.17: Solvent circuit
14.2 Spare parts and accessories
Use only genuine BUCHI consumables and spare parts in order to ensure correct,
safe and reliable operation of the system.
NOTE
Any modifications of spare parts or assemblies are only allowed with the prior written
permission of BUCHI.
14.2.1 Spare parts
Order no. Image
Extraction glass chamber Soxhlet 11062496
Extraction glass chamber Soxhlet LSV 11062497
