11 | Cleaning and servicing BÜCHI Labortechnik AG
76/88 Operation Manual FatExtractor E-500
u Close the tank valve.
11.3.3 Switch of the pump
Navigation path
➔ ➔ [Service] ➔ [Actors]
u Navigate to [Actors] via the navigation path.
ð The display shows the view Actors.
u Disable the action [Pump].
11.4 Draining solvent from Extraction glass chamber (Soxhlet only)
Navigation path
➔ ➔ [Service] ➔ [Actors] ➔
[Valves]
Precondition:
R Solvent remains in the extraction glass chamber.
R The lift is in the lower position.
R The instrument has ambient temperature.
R A beaker is placed under the extraction glass chamber Soxhlet position.
u Navigate to [Valves] via the navigation path.
ð The display shows the view Valves.
u Select the position of the Soxhlet valve you wish to open.
u Open the Soxhlet valve.
u Wait until the extraction glass chamber is empty.
u Close Soxhlet valve.
