Entering system settings (Service menu – Settings)
6
RC35 programming unit - Technical specifications are subject to change without prior notice.
27
Max flow temp. Radiator, convector: 75°C
30°C to 90°C
Floor: 50°C
30°C to 60°C
Setting entered only if the control
mode has been set to outside
temp. controlled (see page 31).
Enter the maximum flow
temperature:
Setting entered only if the control
mode has been set to room temp.
controlled (see page 31).
Min flow temp. 5°C
5°C to 70°C
Setting entered only if the control
mode has been set to outside
temp. controlled (see page 31).
Enter the minimum flow
temperature:
Setting entered only if the control
mode has been set to room temp.
controlled (see page 31).
Rm. tmp offset 0.0K
-5.0K to +5.0K
Offset of heating characteristic
curve.
Setting entered only if the control
mode has been set to outside
temp. controlled (see page 31).
Enter the maximum room
influence:
3K
0K to 10K
Setting entered only if the control
mode has been set to outside
temp. controlled (see page 30).
Which type of reduction
should be implemented?
Outdoor setback mode,
reduced operation, room
setback mode (only if RC35
or RC20 has been assigned
to the heating circuit), shut-
down mode
Night setback
(see page 32)
What outside temperature
should be used for reduced
operation?
5°C
-20°C to +10°C
Temperature threshold for outdoor
setback mode (see page 32).
Setting entered only if the reduc-
tion mode has been set to outdoor
setback mode.
Frost protection
What temp. should be
used to trigger frost pro-
tection?
Outside temperature,
room temperature, no frost
protection
Room temperature can only be set
if RC20 or RC35 has been
assigned to the heating circuit (see
page 33).
Which frost protection
temp. should be used?
5°C
-20°C to +10°C
Refers to outside temperature (see
page 33).
Menu item
Input range
Factory setting in bold Other information
Table 11 Navigator for Service menu SETTINGS \ HTG. CIRC. 1
