73
METERS
Configuration for the ARC Plus metering channels is broken out into several tabs in the main display area of
AutoLoad Plus. Complete the configuration fields on each tab to set up your analog metering inputs.
METER CHANNELS
The Meter Channels tab permits entry of the channel label, units label, sample type, decimal place and source.
CHANNEL AND UNITS LABELS
Under the Label and Units Label headings, enter names for the metering channel and the unit of measurement.
These labels appear on the front panel, web page, and in AutoPilot.
