Note:A strain relief for the 230 volt connection socket is provided on the mattress base
frame, in the centre of the bed under the seat section (see [b]). This strain relief applies
for the bed variants Dali econ, low-econ, low-entry-econ.
Please note:The 230 volt cable is ready-installed in the factory and fixed in place un-
der the mattress base frame.
• Simply insert the power plug into the electrical socket.
Attention: The following instructions apply only for Dali low-entry and Dali low-entry-econ:
Incorrect cable routing!
The connecting cable is sub-
jected to bending stress
caused by the movement of
the mattress base. In addi-
tion, the crossbar of the mat-
tress base rubs against the
sheathing.
Assembling the Care Bed
20 Part B: Operator and Technical Personnel
