BVL V-MIX Fix - V-MIX Fix Plus 13-2 S to 30 H2 S

Technical data
V-Mix Fix Plus
109165
Translation of original operating manual
33
3.2 V-MIX Fix Plus 13-2S to 30H2S
Model
Unit
13-2S
15-2S
15N-2S
17-2S
17N-2S
Capacity
m³
13
14.8
15.4
16.6
17.1
Mixing chamber overall length
mm
4860
4975
5300
5060
5380
Mixing chamber overall width
mm
2050
2050
2270
2050
2270
Total width in case of single discharge
mm
2160
2160
2380
2160
2380
Total width in case of double discharge
mm
2260
2260
2480
2260
2480
Machine height with standard equipment,
measured from the lower edge of the
base plate
(700 mm support frame)
mm
2400
2600
2330
2800
2480
Minimum machine height with standard
equipment, measured from the lower
edge of the base plate
(600 mm support frame)
mm
2300
2500
2230
2700
2380
Empty weight
kg
4900
5300
6000
5500
6330
Model
Unit
20-2S
20H-2S
22-2S
24H-2S
24-2S
Capacity
m³
18.7
19.8
21.5
23.2
23.2
Mixing chamber overall length
mm
5590
5515
5660
5675
5795
Mixing chamber overall width
mm
2370
2270
2370
2270
2370
Total width in case of single discharge
mm
2480
2380
2470
2355
2480
Total width in case of double discharge
mm
2580
2480
2600
2485
2580
Machine height with standard equipment,
measured from the lower edge of the
base plate
(700 mm support frame)
mm
2500
2730
2640
3030
2870
Minimum machine height with standard
equipment, measured from the lower
edge of the base plate
(600 mm support frame)
mm
2400
2630
2540
2930
2770
Empty weight
kg
6850
6550
7050
6675
7150
