3.3 Model plate and EC marking
The following figures indicate the placement of model plate, machine number and EC marking.
The overall marking has documentary value and may not be altered or made unrecog-
nizable.
(1) Model plate with EC marking
(2) Machine number (etched into the frame)
Fig. 3-1
Listed on the model plate are:
 Manufacturer
 Model
 Machine number
 Year of manufacture
Fig. 3-2
3.4 Hydraulic aggregate
Manufacturer
DANA Brevini
Laimer Hydraulik
Drive power
1.1 kW
5.5 kW
System pressure
190 bar
150 bar
Volume flow
3.3 l/min
16 l/min
3.5 Load capacity limits
The specific weight of the material to be processed may not exceed 420 kg per m³.
