NICE - MIRIAM - CRISTAL - LEONORA - PRETTY - DIANA - KRISS - MARY
IT
9.2 DIMENSIONI D’INGOMBRO
Fig. 12 - Dimensioni generali
LEGENDA Fig. 12 a pag. 16
1 48,6 - 55 - 57 cm
2 95 cm
3 46,6 - 47 cm
4 26,5 cm
5 17 cm
6 13,2 cm
7 Scarico fumi d.8 cm
8 Presa aria comburente d.4 cm
