7.2 CHIMNEY FLUE
Fig. 2 - Chimney Flues
LEGEND Fig. 2 page 52
1 Chimney ue with insulated stainless-steel pipes
2 Chimney ue on the existing chimney
3 Inspection plug
4 Inspection door
5 ≥ 3,5 mt
• The chimney ue or chimney is of great importance for the correct running of the heating appliance.
• It is fundamental that the chimney ue is perfectly built and always maintained with a perfect efciency.
• The chimney ue must be sole (see Fig. 2 page 52) with insulated stainless-steel pipes (1) or installed
on the existing chimney ue (2).
• Both this solutions must be endowed with an inspection plug (3) and/or an inspection door (4).
It is forbidden to connect more pellet stoves or any other heating appliance to the
same chimney ue.
