9.3 GENERAL INSTALLATION
Fig. 13 - General installation
LEGEND Fig. 13 page 61
1 Stove
2 Minimum lateral distance = 300 mm
3 Minimum rear distance = 200 mm
4 Minimum front distance = 1000 mm
• Please check that the oor has an adequate load capacity. If the existing one does not satisfy this
requirement, appropriate measure should be provided (for example a plate for distributing the load).
• It is obligatory to install the stove away from walls and/or pieces of furniture, with a minimum air ow of
300 mm on the sides and 200 mm on the back, to enable an ecient appliance cooling and a good
distribution of heat in the room (see Fig. 13 page 61).
• For safety re regulations the distances from ammable or sensible to heat objects (sofas, pieces of
furniture, wooden covering, etc...) must be respected, has described in Fig. 13 page 61.
• If there are highly ammable objects (curtains, tted carpet, etc...), all these distances must be further
increased with 1 meter.
• If the walls are made up of ammable materials, check the safety distances (see Fig. 13 page 61).
• At maximum power check that the wall temperature does not ever exceed 80°C. If it would be necessary
please install a re resistant plate on the concerned walls.
• In some countries also masonring load-bearing walls are considered ammable.
9.4 SIDE PANEL ASSEMBLY
Fig. 14 - Upper screws removal Fig. 15 - Backward screws removal
• Remove the top cover: unscrew the 2 upper screws and the 3 backward screws (see Fig. 14 page 61
