To
install the storage system:
1.
Pull the carpeting from the floor of the
trunk.
Turn
the retainer (center dial) on the compact spare tire
cover to the left to remove it.
2.
Place the
trunk
storage system on the center of the
trunk floor.(the cut out portion of the storage system
should be facing the rear of the vehicle).
3.
Open the storage system by pulling up on the handle
located in the carpeted area. This allows the unit to
fold up into place. Fold the divider walls open and
move them into the retention slots.
4.
Remove the rectangular access panel from the floor
of
the storage system. The access panel should
unsnap'by hand.
5.
Center the storage system access hole over the area
where the spare tire is secured by the retainer.
Position the storage system as needed and then
secure
it
with the retainer.
6.;
Replace the access panel.
7.
Attach the removable net to the slots located on the
front of the divider walls and attach the hooks to the
holes on each side of the storage system.
Once in place, the storage system can be moved
forward or rearward for convenience and easy access
of
stored items.
The following steps explain how to remove the
trunk
storage system for cleaning or in case
you
need to access
the spare tire. Follow
all
of these steps
if
the storage
system is in the closed position. Begin with Step
2
if
the
system is already open.
1.
2.
3.
4.
Open the storage system by pulling up on the handle
located in the carpeted area.
This
allows the unit to
fold up into place. Fold the divider walls open and
move them into the retention slots.
Remove the rectangular access panel from the floor
of the storage system. The access panel should
unsnap by hand.
Center the storage system access hole over the &ea
where the spare tire
is
secured by the retainer.
Position the storage system as needed and then
remove the retainer
(turn
the retainer to the left to
remove it).
Replace the access panel and remove the
storage system.
2-12
