CAME BK Series User Manual

U V W
FC FA F
E1 EX W
CAME
10 11 TS 1 2 3 3P 4 5
L N
L1T L2T CT VS VF
24V 0
10 11
0
17
24
FR
1
2
3
4
SP
0
p. 15 - Manual FA00442-EN - 12/2017 - © CAME S.p.A. - Translated original instructions
Opening limit-switch
micro-switch
FACTORY WIRING
Flashing light connection output (contact
rated at: 24 V AC - 25 W max).
SIGNALING DEVICES
Closing limit-switch
micro-switch
WHITE
RED
ORANGE
Condenser230V (AC) Gearmotor
Gate open signal
output (contact rated
at: 24 V AC - 3 W
max).
See function
F10.
Additional light connection output (contact
rated at: 230 V - 60 W max).
See function F18.
Accessories power
supply output 24 V
AC, max 20 W.
 To vary the motor torque, move
the shown faston to one of the four
positions; from 1 (min.) to 4 (max.).
Orange
Blue
Brown
Gray
Black
White
Red
120 / 230 V AC 50/60 Hz
POWER SUPPLY
COM
NC
COM
NC

CAME BK Series Specifications

General

Motor Voltage	230 V AC
Operating Temperature	-20°C to +55°C
Power Supply	230V AC
Motor Power	300W
Limit Switch Type	Mechanical
Safety Features	Obstacle detection
