Important

• Do not move the Carriage over jammed paper. This may damage the Printhead.

• Do not touch the Linear Scale (a) or Carriage Shaft (b). This may stain your hands and damage the

printer.

•

If paper from a roll is jammed by the Paper Feed Slot

1. Open the Roll Feed Unit Cover.

2. Remove the jammed paper from the Paper Feed Slot.

After removing the paper, make sure there are no other scraps of paper in the printer.

Troubleshooting

Problems Regarding Paper

Clearing Jammed Roll Paper iPF6300S

1016
