If paper is jammed deep in the Paper Feed Slot, remove the roll feed unit, and then clear the paper jam.

(See "Clearing Jammed Paper (Paper Feed Slot).") →P.1013

•

If the paper is jammed by the Ejection Guide

Remove the jammed paper from the Output Tray.

After removing the paper, make sure there are no other scraps of paper in the printer.

4. Press the OK button.

Troubleshooting

Problems Regarding Paper

iPF6300S Clearing Jammed Roll Paper

1017
