3-CONTROLSANDINSTRUMENTS

Objectstoragebox

Locatedontheleft-handsideofthecab.Thiscompart-

ment(1)isintendedforstoringobjectsofvarioustypes.

LEEN11T0070AA7

Frontandrearwindshieldwasherreservoir

Thisreservoir(1)islocatedontheleft-handsideofthe

cabandhastwoelectricpumpscontrolledbyaswitchor

bytheleverforthedirectionindicators,mainbeams,front

windshieldwiperandwasher.

NOTE:Incoldweather,useawindshieldwasherwithlow

temperaturecapability.

NOTICE:Neveroperatethewindshieldwasherwhenthe

reservoirisempty,sincethismaydamagetheelectric

pumps.

LEEN11T0069AA8

3-44
