Case 590ST - Recovery Transport; Towing the Machine

5-TRANSPORTOPERATIONS
RECOVERYTRANSPORT
Towingthemachine
WARNING
Misusehazard!
Towingisadelicatemaneuverthatisalwayscarriedoutattheriskoftheuser.Themanufacturer's
warrantydoesnotapplytoincidentsoraccidentsthatoccurduringtowing.Wherepossible,carryout
therepairsatthesite.
Failuretocomplycouldresultindeathorseriousinjury.
W0286A
WARNING
Lossofcontrolhazard!
Avoidusingdifferentiallockatspeedsabove8km/h(5mph).Neveruseatspeedsabove15km/h(9
mph)oratanytimewhenturningthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0334A
WARNING
Transporthazard!
Whentowingonroughterrainorbetweeneldoperations,alwaysdothefollowing:Engagethetrans-
portpin.Installasafetychainbetweenthemachineandtowedvehicle.Thispreventsaccidental
releaseofthetowedvehicle.
Failuretocomplycouldresultindeathorseriousinjury.
W1121A
WARNING
Hazardtobystanders!
Theoperatormustbetheonlypersononthemachinewhentowing.Makesurethatnobodyelseison
themachineorwithinitsworkingrange.
Failuretocomplycouldresultindeathorseriousinjury.
W0259A
NOTE:Theinstrumentsrepresentedmaynotexactlycorrespondtotheinstrumentsonyourmachine.
Towthemachineonlyincaseoffailure.
Makesurethatitcanbetowedwithoutcausingfurther
damage.
1.Wheneverpossiblecarryouttherepairatthesiteor
consultyourDealer.
2.Ifthemachineisonthepublichighway,makesure
thatnocomponentofthemachineprojectsontothe
highway.Ifthiscannotbeavoided,installsignsin
compliancewiththerelevantregulations.
3.Ifthemachinehastobetowedwiththeengineshut
down,itisnecessarytouncouplethefrontandrear
(4WD)transmissionshafts.
4.Beforetowing,besuretodothefollowing.
5.Checkthatsteeringcanbeused.
6.Checkthatthedirection-of-travelcontrollever(1)isin
theneutralposition.
LEEN11T0202AA1
5-12
