Case 590ST - Fuses - Replacement

7-MAINTENANCE
Fuses-replacement
NOTICE:Neverreplaceafusewithafuseofadifferentrating.
Thefuseandrelaycontrolunitislocatedundertheside
instrumentpanel.
Neartothefuseandrelaycontrolunitislocatedalso
anotherfuse:
5Afuse:
•
Diagnostics
•
Scrollswitches
•
Menu/enterswitches
•
(+30)anti-theftdevice
MOLI12LBB0485AA1
Themainfuseisinthebatterycompartment.
•
80Afuse:Protectionbetweenthebatteryandthe
machine’selectricalsystem.
MOLI12LBB0486AA2
Onthefrontright-handsidebehindtheengineyouwill
ndthefusesandrelaysfortheEngineControlUnit
(ECU),theair-conditioningunit,andstarter.
Thefusesandrelaysusedareasfollows:
•
30Afuse:Air-conditioning3rdspeed(iftted).
•
30Afuse:EngineControlUnit(ECU).
•
10Afuse:Air-conditioning(iftted).
•
5Afuse:Fuelprelter.
•
7.5Afuse:Gridheater.
•
No.3relays:Starter.
•
Relay:Air-conditioning(iftted).
MOLI12LBB0487AA3
Undertheseatbase:
•
25Afuse:Blowermotor(iftted)3rdspeed.
NOTE:Youmustremovetheseattoaccesstheblower
motorfuse.
7-118
