3-CONTROLSANDINSTRUMENTS
Pedalcontrols
Engineaccelerator
Locatedunderthesteeringwheel,thispedal(1)enables
theenginespeedtobeincreasedordecreased.
Pressthepedaltoincreasetheenginespeed.
Releasethepedaltoreducetheenginespeed.
Thispedalisusedfortravelandforoperatingtheloader
attachment.
NOTE:Thispedaliscoupledwiththeengineaccelerator
knob.Beforeusingthepedal,makesurethatthemanual
acceleratorisintheminimumspeedposition.
NOTICE:NEVERusethispedalwhenworkingwiththe
backhoeattachment.
LEEN11T0052AA1
Brakepedals
WARNING
Lossofcontrolhazard!
Brakepedalsshallbelockedtogetherforroadtravel.Thisensuresuniformbrakeapplicationand
maximumstoppingability.
Failuretocomplycouldresultindeathorseriousinjury.
W0308A
Locatedunderthesteeringwheel,thesetwopedals(1)
areequippedwithasystem(2)whichenablesthemtobe
lockedtogetherorunlocked.Thisenablesthemachine
eithertobebraked(pedalslocked)bypressingeitherof
thepedalsortobeturned(pedalsunlocked)totherightby
pressingontheright-handpedalortotheleftbypressing
ontheleft-handpedal.Brakingwithonepedalonlyshould
onlybecarriedoutatlowspeed.
NOTE:Onthefrontcontrolpanel,the2/4wheeldrive
switchlightturnsOnwhenthepedalsarelockedandthe
brakesareapplied
Tolockthetwopedalstogether,tiltthelatchsoitengages
ontheright-handpedal.
LEEN11T0055AA2
3-16
