Parkingbrakelever
DANGER
Run-overhazard!
Applytheparkingbrakebeforeleavingthecab.
Failuretocomplywillresultindeathorseriousinjury.
D0028A
WARNING
Avoidinjuryand/ormachinedamage!
Applytheparkingbrakeonlywhenthemachineisstationary.Whiledriving,applytheparkingbrake
onlyinanemergency.Thebrakingactionisabrupt.
Failuretocomplycouldresultindeathorseriousinjury.
W1132A
WARNING
Unexpectedmachinemovement!
Beforeyouturntheoperator'sseataroundtothebackhoeoperationposition,shiftthedirectioncon-
trolleverandthetransmissiontoneutralandapplytheparkingbrake.
Failuretocomplycouldresultindeathorseriousinjury.
W0194A
Locatedontherightoftheoperator’sseat(withtheseat
intheloaderattachmentposition),thislever(1)enables
themachinetobeimmobilized.
Raisethelevertoimmobilizethemachine(wheels
braked).Inthisposition,theindicatorlamponthein-
strumentpanelturnson.Pressandholddownthepush
buttononthetipoftheleverandthenlowerthelever
toreleasethebrakes(wheelsarefreetorotate).Inthis
position,thelampontheinstrumentpanelisout.
Ifthegearisengagedwhentheparkingbrakeisactivated,
itwillactuatethewarningbuzzerandthesymbol“parking
brakealarm”willappearonthedisplay.
NOTICE:NEVERtrytomovethemachinewhenthelever
isintheraisedposition.
NOTICE:Beforestoppingtheengine,makesurethelever
isintheraisedposition.
WARNING
Equipmentfailurecouldcauseaccidentorin-
jury!
Beforeoperatingthemachine,checkforcor-
rectoperationofsteering,brakes,hydraulic
controls,instruments,andsafetyequipment.
Makesurethetransmissioncontrolleverisin
theneutralposition.Makealladjustmentsbe-
foreoperatingthemachine.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0204A
