Case 590ST - Engine Oil Level Check and Specification

7-MAINTENANCE
Engineoillevel
1.Movethemachinetoalevelandrmground.
2.Raisetheloaderattachmentandinstallthesafetysup-
portstrut.
3.Placethebackhoeattachmentintheroadtravelposi-
tion.
4.Placethedirection-of-travelleverandgearshiftleverin
neutralposition.
5.Immobilizethemachinewiththeparkingbrake.
6.Stoptheengine,waitforittocooldownandremove
thestarterswitchkey.
7.Releaseanypossibleresidualpressurefromthehy-
draulicsystembymovingthecontrolleversinalldirec-
tions.
LEEN11T0354AA1
8.Locktheattachmentcontrols(specictocertaincoun-
tries).
9.Placesomewedgesunderthewheelsinordertopre-
ventthemachinefrommoving.
10.Openandraisetheengineguard.
11.Extractthedipstick(1),cleanitwithacleancloth
andcompletelyinsertitintothehose,thentakeitout
again.
RAIL15TLB0174AA2
12.Iftheoillevelisbelowtheaddmark,removetheller
cap(2)andaddoiluptothefullmarkonthedipstick.
13.Retightenthellercap(2).
LEEN11T0361AA3
14.Lowerandlocktheengineguard.
15.Removethesafetysupportstrutandlowertheloader
attachment.
7-20
