1-GENERALINFORMATION

Operator'smanualstorageonthemachine

KeeptheOperator'sManualinthestoragecompartment

providedontherearoftheoperator’sseat.TheOpera-

tor'sManualmustbeavailableforusebyalloperators.

LEEN11T0064AA1

1-10
