3-CONTROLSANDINSTRUMENTS

OPERATOR'SSEAT

Operator'sseat

CAUTION

Avoidinjury!

Beforeoperatingthemachine,andwheneveranewoperatortakesover,adjusttheseatsuspension

tosuittheoperator’sspecicweight.

Failuretocomplycouldresultinminorormoderateinjury.

C0093A

WARNING

Roll-overhazard!

Securelyfastentheseatbelt.YourmachineisequippedwithaRoll-OverProtectiveStructure(ROPS)

cabforyourprotection.Theseatbeltcanhelpensureyoursafetyifitisproperlyusedandmaintained.

Neverwearaseatbeltlooselyorwithslackinthebeltsystem.

Failuretocomplycouldresultindeathorseriousinjury.

W0376A

Tooperatethemachinecorrectlywithmaximumefciency

andcomfort,checkthattheoperator’sseatanditsadjust-

mentcontrolsareingoodconditionandthenadjustthe

seattosuittheoperator’ssizeandweight.

NOTE:TheseatcomplieswithstandardISO7096:2000

classEM5.

MOLI12LBB0154AA1

3-4
