Case 590ST - Loader Attachment Controls

3-CONTROLSANDINSTRUMENTS
Loaderattachmentcontrols
WARNING
Misusehazard!
Beforestartingtheengine,makesureyouare
fullyawareofthelocationandthefunctionof
eachcontrol.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0226A
WARNING
Avoidinjury!
Beforestartingtheengine,securelyfastenthe
seatbelt.Theseatbeltcanhelpensureyour
safetyifitisproperlyusedandmaintained.
Neverwearaseatbeltlooselyorwithslack
inthebeltsystem.Neverwearthebeltifit
istwistedorpinchedbetweentheseatstruc-
tures.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0142A
Withstandardloaderbucket
Locatedontherightofthesteeringwheel,thisnineposi-
tionleveroperatesalltheloaderattachmentcontrols.The
speedofmovementofeachcontroldependsontheangle
towhichtheleveristilted.Intheintermediateposition,
twomovementscanbeobtainedsimultaneously.
With4x1loaderbucket
Thefunctionoftheleverisidenticaltothatofthemachine
ttedwiththestandardloaderbucket,withtheadditionof
theclamcontrol.
3-50
