Case 590ST - Right-Hand Side Controls; Ignition Switch

3-CONTROLSANDINSTRUMENTS
RIGHT-HANDSIDECONTROLS
Ignitionswitch
NOTE:Theinstrumentsrepresentedmaynotexactlycorrespondtotheinstrumentsonyourmachine.
Starterswitchkey
WARNING
Misusehazard!
Beforestartingtheengine,makesureyouare
fullyawareofthelocationandthefunctionof
eachcontrol.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0226A
Locatedontherightoftheoperator’sseat(withseatin
loaderattachmentposition),thisswitchhasfourpositions:
Position1:Notused.
Position2:Stop.
Position3:Contact(theaudiblealarmsounds).
Position4:Start.
LEEN11T0037AA1
NOTE:Thiskeycanbeusedtolockthecabdoors,the
engineguard,andthefueltankplug.
3-25
