Case 590ST - Control Panel and Side Instrument (580 T Mechanical Motor)

3-CONTROLSANDINSTRUMENTS
Controlpanelandsideinstrument(580Tmechanicalmotor)
LEIL12TLB00005I1
1.Frontworklightswitch:Thisswitchhasthree
positions:
•
TherstpositionisOFF(controllampoff).
•
Secondposition,bypressingthesymbolside(rst
click)theouterfrontworklightsareturnedon(con-
trollampon).
•
Thirdposition,bypressingthesymbolsideagain
(secondclick)theinnerfrontworklightsareturned
ontoo(controllampon).
2.Lightswitch:Thisswitchhasthreepositions:
•
TherstpositionisOFF(controllampoff).
•
Secondposition,bypressingthesymbolside(rst
click)theinstrumentclusterpanelispowered,the
sidelightsandthelowbeamindicatorlampare
turnedon(controllampon).
•
Thirdposition,bypressingthesymbolsideagain
(secondclick)thehighbeamsareenabledandthe
lowbeamsandthelowbeamindicatorlampare
turnedon(controllampon).
3.Sideworklightswitch(Optional):Thisswitchhas
twopositions:
•
TherstpositionisOFF(controllampoff).
•
Secondposition,bypressingthesymbolside,the
sideworklightsturnonatthesametime(control
lampon).
4.Backhoeattachmentlockingswitch:
•
Theswitchisusedtolockorunlockthebackhoeat-
tachmentsafetyhookinpreparationforroadtravel.
5.Rearworklightswitch:Thisswitchhasthree
positions:
•
TherstpositionisOFF(controllampoff).
•
Secondposition,bypressingthesymbolside(rst
click)theouterrearworklightsareturnedon(con-
trollampon).
•
Thirdposition,bypressingthesymbolsideagain
(secondclick)theinnerrearworklightsareturned
ontoo(controllampon).
6.Sideinstrumentcluster:SeePage3-34fordetails.
7.Backhoeattachmentquickcouplerswitch(Optional):
•
Pressbothswitchestoactivatethequickcoupler
ofthebackhoeattachment.
•
Pressonthe2switchestounlock(retractpins)
ofquickcoupleronbackhoeattachment.
•
Press
onthe2switchestolock(extendpins)
ofquickcoupleronbackhoeattachment.
8.Rearwindshieldwiperandwasherswitch:This
switchhasthreepositions:
•
TherstpositionisOFF(lampoff)andboththe
windshieldwiperandthewindshieldwasherare
disabled.
•
Thesecondpositionallowstopressthesymbol
sideoftheswitchtoactivatetherearwindshield
wiper(lampon).
•
Thethirdposition,allowstopressthesymbolside
oftheswitchandholdtoactivatethewindshield
washer(lampon).Whenreleasingtheswitch,the
windshieldwasherstopsandthewindshieldwiper
startsmoving.
9.Backhoeattachmentsideshiftcarriagehydraulic
shiftingswitch:
•
Thisswitchallowshydraulicallymovingtheback-
hoeattachmenttowardsthetracksides.
3-30
