3-CONTROLSANDINSTRUMENTS
•
Thethirdposition,allowstopressthesymbolside
oftheswitchandholdtoactivatethewindshield
washer(lampon).Whenreleasingtheswitch,the
windshieldwasherstopsandthewindshieldwiper
startsmoving.
10.Backhoeattachmentsideshiftcarriagehydraulic
shiftingswitch:
•
Thisswitchallowshydraulicallymovingtheback-
hoeattachmenttowardsthetracksides.
•
Presstheswitchontheuppersideofthesymbol
toshiftthebackhoeattachmenttotheright
sideofthetrack.
•
Presstheswitchonthelowersideofthesymbol
toshiftthebackhoeattachmenttotheleftside
ofthetrack(tracksidesarereferredtothetravel
directionofthemachine).
11.Hornswitch:(onlymodelswithmechanicalbackhoe
controls):
•
Thisswitchoperatesthewarninghorn.
12.Backhoeattachmentquickcouplerswitch(Optional):
•
Pressbothswitchestoactivatethequickcoupler
ofthebackhoeattachment.
•
Pressonthe2switchestounlock(retractpins)
ofquickcoupleronbackhoeattachment.
•
Pressonthe2switchestolock(extendpins)
ofquickcoupleronbackhoeattachment.
13.Backhoeattachmentsideshiftcarriagelocking
switch(Sideshiftversion)
•
Itallowslocking(controllampon)orunlocking
(controllampoff)theslidingcarriagethebackhoe
attachmentismountedon.
3-29
