Case 590ST - Exterior Controls; Rotating Beacon (Optional)

To Next Page

To Previous Page

3-CONTROLSANDINSTRUMENTS

EXTERIORCONTROLS

Rotatingbeacon(Optional)

Therotatingbeacon(1)shouldbeplacedonthecabroof

andthecableconnectedtooneofthe12Vsocketsover

thedooroneachsideofthemachine.

NOTICE:Therotatingbeaconmustbeinstalledandop-

eratedwhenundertakingroadtravel

LEEN11T0081AA1
