6-WORKINGOPERATIONS

LOADERATTACHMENT

Organizingthejobsite

Usetheshortestpossibleworkcycles.Thelocationpro-

videdforthetrucksisanallimportantelement.Spenda

littletimelevelingtheworkarea.

Asmoothworkingsurfacefacilitatestheworkofthe

machineandmovingandparkingthetrucks.Itgivesa

shorterworkcycle.

WARNING

Lossofcontrolhazard!

Afullbucketintheraisedpositionmaycause

themachinetoslidewhenoperatingover

roughground.Keepthebucketaslowas

possibleduringoperationforbetterstability

andvisibility.Alwaysoperatethemachineat

slowspeedsoverroughground.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0271A

MOLI12LBB0259AA1

6-5
