1-GENERALINFORMATION

Cab

CabwithacertiedRollOverProtectiveStructure(ROPS)

andFallingObjectProtectiveStructure(FOPS).

Model:

PIN:

LEEN11T0346AA10

Canopy

CanopywithacertiedRollOverProtectiveStructure

(ROPS)andFallingObjectProtectiveStructure(FOPS).

Model:

PIN:

LEEN11T0347AA11

1-9
