3-CONTROLSANDINSTRUMENTS

Lockingthebackhoeattachmentmechanicalcontrols(Specictocertaincountries)

Thepin(1)locatedinfrontofthestabilizercontrollevers,

isusedtolockthebackhoeattachmentcontrols.

LEEN11T0316AA9

Tolockthecontrols,removethepinfromitshousingand

installitinthespeciallyprovidedholeintheconsole.

NOTICE:Beforeleavingtheoperator’scompartment,un-

dertakinganyroadtravelorworkingwiththebackhoeat-

tachment,placethepininlockingposition.

LEEN11T0317AA10

3-69
