1-GENERALINFORMATION

590STand695STengine

FiatPowertrainTechnologies(FPT)82kW(111Hp)

F4HE9484C(590ST)orF4HE9484C(695ST).

PIN:

LEEN11T0339AA3

Powershuttletransmission

Model:

PIN:

LEEN11T0340AA4

Powershifttransmission

Model:

PIN:

LEEN11T0341AA5

1-7
