Case 590ST - Page 350

7-MAINTENANCE
Fuses
FuseNo.RatingFunction
F1A15ARearwindshieldwiperandwasher
F1B7.5A
(+15)anti-theftdevice
F1C
10A
4WD,transmissiondisconnectionanddifferentiallock
F2A15AInstrumentpowersupply,switchlamps,pneumatic-electricseat
F2B15AAir-conditioning
F2C
15APilotcontrol
F3A3A
Rearright/frontleftsidelight,instrumentbacklighting
F3B3A
Rearleft/frontrightsidelights,numberplatelight
F3C
10AFrontworklightswitch,ridecontrol,4x1bucket
F4A7.5A
Stoplightswitch
F4B10ARearhammerbutton,bucketlevelsolenoidvalve+sensor
F4C
10ABackhoeattachmentlock,backhoeattachmenttravellock,backhoeattachment
travellockswitch
F5A15A
Innerfrontworklights
F5B10ALowbeams
F5C
15AMainbeams
F6A15ARotatingbeacon
F6B7.5A
(+15)hazardwarninglightpowersupply
F6C
7.5A
Quickcoupler
F7A10A
(+30)powersupplyforhazardwarninglights,horn
F7B10A
Electricalsocket,radio,rooflamp
F7C
6AFrontwindshieldwiper
F8A15A
Outerrearworklights
F8B15A
Outerfrontworklights
F8C
15AInnerrearworklights
Relays
K1AFlasher
K3
Startingrelay
K4Bucketlevelsolenoidvalverelay
K5Lowandmainbeamrelay
K6
Innerfrontworklightrelay
K7Innerrearworklightrelay
K8
Outerfrontworklightrelay
K9
Outerrearworklightrelay
K10
Optionalrelay
7-128
