9-SPECIFICATIONS

Performanceofloaderattachmentwithforks

580T/580STwithstraightloaderarms

RAIL15TLB0564FA7

Maximumheightofloaderbucketpin/pivotwithliftedforks3490mm(137.4in)

Forkmaximumheight

2982mm(117.4in)

Heightofloaderbucketpin/pivotofloaderbucketwithloweredforks497mm(19.6in)

DForkreachwhenraised

2232mm(87.9in)

EForkreachwhenlowered

2741mm(107.9in)
