2-SAFETYINFORMATION

Moveawayfromme

MOLI12LBB0072AA4

Gothisfar

MOLI12LBB0073AA5

Stopallandhold

MOLI12LBB0074AA6

Stop

MOLI12LBB0075AA7

2-20
