2-SAFETYINFORMATION

Backhoedipperout

MOLI12LBB0088AA20

Backhoebucketdig

MOLI12LBB0089AA21

Backhoebucketdump

MOLI12LBB0090AA22

Retracttelescopicdipper(Iftted)

MOLI12LBB0091AA23

2-24
