2-SAFETYINFORMATION

(14)Hydraulicuidonly

Makesurethatyouonlyllareservoirbearingthissign

withhydraulicuid.Seepage7-7.

Location:

Right-handsideofthemachineonthehydraulictank.

Quantity:1

Partnumber:

85804341

LEEN11T0450AA18

(15)Batteryhazard

WARNING!

Explosionhazard.Runoverhazard.Readprocedurein

Operator’sManualbeforejumpstartorservicetoavoid

injury.Failuretocomplywillresultindeathorserious

injury.

Location:

Right-handsideofthemachineonthebattery

compartment.

Quantity:1

Partnumber:

85804330

LEEN11T0448AA19
