3-CONTROLSANDINSTRUMENTS
Exitingthemachine:
1.CanopymachinesproceedtoStep4.
2.Pullthehandle(1)downwardtoopenthedoorfrom
theinside.
3.Fullyopenthedoor.
4.Usethestepsandgrabhandleswhenexitingtheop-
erator’scompartment.Alwaysmaintainthreepointsof
contactwiththemachinestepsandgrabhandles.
5.Maintainasecuregripandsolidfootinguntilyouare
standingontheground.
6.Ifapplicable,closeandlockthedoor.
NOTE:Usethestarterswitchkeytolockthedoors.
RCPH10TLB333AAF3
Cabdoorwindowandsidewindowoperation
NOTICE:Donotallowthewindowstoswingfreely,always
securethewindowposition.
NOTICE:Whenopeningorclosingwindows,alwayshold
themrmlyuntiltheyarecompletelylockedinposition.
Holdpartiallyopen:
Raisethehandle(1)andpushitoutwardsanddown-
wardstolockthewindowinapartiallyopenedposition.
Holdfullyopen:
1.Thewindowmustbeintheclosedposition,raisethe
handle(1)tothehorizontalpositionandthentiltitrear-
wardstodisengageitfromthepin.
2.Openthewindowuntilitengagesintherubberlocking
device(2).Makesurethatthewindowissecure.
Closeandlockthewindow:
1.Pullknob(3)todisengagethewindowfromtherubber
lockingdevice(2)
2.Closethewindowandmakesurethatthewindowhan-
dle(1)completelyengagesinthelockpin.
3.Pushthewindowhandle(1)downwardstosecurethe
window.
LEEN11T0060AA4
LEEN11T0061AA5
