3-CONTROLSANDINSTRUMENTS
Thetransmissionprovidesfourforwardandfourreverse
speeds.Atorqueconverterisusedtocoupletheengine
withthetransmission.
Thedirectionoftravellever(3)allowsshiftingbetween
forwardandreversetravelwithoutdisengagingthegear
ratios.
Adevicefor“transmissiondisconnection”isactivatedby
pushingbutton(2),placedonthegearshiftlever(1)or
bypushingbutton(5),placedontheloaderattachment
controllever.
LEEN11T0045AA2
Gearshiftlever
Thegearshiftlever(1)isusedtoselectanyofthefour
gearratios.
Thetransmissiondisconnectbutton(2)isdepressedand
heldastheleverisshiftedfromonegeartoanother.The
buttonisthenreleasedtoreestablishthepoweroftrans-
missiondrive.
LEEN11T0044AA3
