A.5 TPIM Port
The following table shows the pin-out for the TPIM 10-way RJ45 connector.
PIN SIGNAL DESCRIPTION
2 TX+ Transmit Data +
3 TX
– Transmit Data –
4 RX+ Receive Data +
7 RX
– Receive Data –
All remaining pins are unused.
X870-300351 Issue 1 A-3 Rev.0
