4.4.3 Configure Protocols Form (conf prot command)
This form allows each of the LAN protocols to be configured for correct
operation.
Router : Watford CONFIGURE PROTOCOLS FORM Rel x.y
--------------------------------------------------------------------------------
MAC Ethernet Address : 00:00:60:00:00:02
Framing Protocol : Ethernet
IP Internet address : 001.001.001.001
Subnet mask : 255.000.000.000
Fragmentation : 576
Time to Live : 32
WARNING : Changes to IP parameters will only take effect after a warm restart.
TCP Window size : 512 Keepalive : ENABLE
Max segment size : 536 Keepalive Time : 30
Initial RTT : 5
PAD X.121 Address : 11000017050
RSET from X.25 : Enabled
--------------------------------------------------------------------------------
^PF2 - Help ^R - Restore
^PF1 - Submit ^C - Abort
--------------------------------------------------------------------------------
MAC Ethernet Address (Information)
This displays the fixed Ethernet address (hexadecimal).
MAC Framing Protocol (Information)
This displays the MAC framing method.
Ethernet – Ethernet (Xerox, DEC, Intel) framing standard
IP Internet Address (Free Format Text, 20)
This is a mandatory field. It contains an Internet Address. This address
represents the Internet Address of this device; it is used in the generation
of IP datagrams and handling ARP packets. See Appendix C.2.
IP Subnet Mask (Free Format Text, 20)
This field defines the 'network' or 'subnet' part of the IP address designed
for Router. Bit positions in this mask identify which bits in the IP address
are significant when determining if an address for a destination device is
on the same network or subnet. This can be used to route according to the
