3 Initial Configuration
This chapter summarises the tasks that need to be carried out when
initially configuring Router. Tasks that are not fully described here, are
described in Chapter 4. An example configuration is given in Appendix E.
3.1 Control Panel Displays
On the 8325 control panel, the TGate/Router has a board ID of T and only
uses the first character in its 'Display Status' field. The character
displayed here corresponds to the operational state of the card. On the
8425 and 8525, the characters are displayed on the TGate/Router card's
LED. Under normal running conditions an
r is displayed. However,
various other characters or sequences of characters may be displayed as
summarised below.
CHARACTER MEANING
b
c
d
o
r
t
(v)
(F)
I
L
P
(0-9)
blank
(others)
booting
running congested
dumping
operational
running
test diags running
vector fault
fault
initialising
loading
poll received from XRMC
failure code
awaiting poll from XRMC
part of failure code
X870-300351 Issue 1 3-1 Rev.0
