4.7.2 Routing Table (rtr rt command)
This screen allows you to page through the local routing table.
Router : Watford ROUTING TABLE STATUS Rel x.y
--------------------------------------------------------------------------------
Item Network Subnet Mask Next Hop Metric TTL i/f
0 001.000.000.000 255.000.000.000 LOCAL 1 999 0
1 100.000.000.000 255.000.000.000 Reading 2 170 1
ED - Edit DE - Delete
--------------------------------------------------------------------------------
PF2 - Help ^B - Prev Page PF4 - Main Menu
^F - Next Page PF3 - Prev Menu
--------------------------------------------------------------------------------
(rtr rt) Enter command :
Item (Information)
This field displays the route number for reference by the EDit and DElete
commands.
Network (Information)
This field displays the network number of the destination network which
may be reached from this Router.
Subnet Mask (Information)
This field displays the subnet mask which will be applied to the network
number of the distribution network.
Next Hop (Information)
This field displays the identity of the next router to which an IP packet
must be sent in order to arrive at its final destination. If the route entry
describes the local LAN network to which the router is connected the field
will contain the word LOCAL. If the next hop is a configured remote router
the field will contain the router's name. If the next hop is not LOCAL or a
remote router the IP address will be shown.
X870-300351 Issue 1 4-55 Rev.0
