Case 845B VHP - Control Levers and Side Console Components

CHAPTER 3 – INSTRUMENTS AND CONTROLS
3-25
GROUP 3
Control lever of manual accelerator, transmission control lever, side
console fuse box, switchboard and power takeoff
1
4A
3A
6
2A
5
SIDE CONSOLE
(845B / 865B / 885B MODELS WITH ZF TRANSMISSION)
1. SIDE CONSOLE FUSE BOX
2A. SWITCHBOARD
3A. CONTROL LEVER OF MANUAL ACCELERATOR
4A. TRANSMISSION CONTROL LEVER
5. POWER TAKEOFF 24V
6. POWER TAKEOFF 12V
1
4B
3B
6
2B
5
SIDE CONSOLE
(845B / 865B / 885B MODELS WITH FUNK TRANSMISSION)
1. SIDE CONSOLE FUSE BOX
2B. SWITCHBOARD
3B. CONTROL LEVER OF MANUAL ACCELERATOR
4B. TRANSMISSION CONTROL LEVER
5. POWER TAKEOFF 24V
6. POWER TAKEOFF 12V
