CHAPTER 3 – INSTRUMENTS AND CONTROLS
3-48
Air Ducts
1
1
CENTER LOWER DUCTS1.
The lower air output ducts perform a 360° turn and have
adjustable opening in order to direct the air and increase
the comfort for the operator.
2
3
WINDSHIELD LATERAL DUCTS2.
WINDSHIELD UPPER DUCTS3.
4
4
4
UPPER DUCTS4.
The upper air output ducts have adjustable opening for
the air direction.
5
5
5
LATERAL PILLAR DUCTS5.
