Cedar Summit F25650 - Page 46

Fig. 8.4
062
Step 8: Front Wall Assembly
Part 2
C: Make sure the assembly is on level ground and (051) SL Side Window Panel and (042) Chalkwall Panel are
square and tight to (040) Cafe Wall Window Panel.
D: Tighten all 10 Wafer Bolts on the front side as shown in g. 8.4.
051
042
040
Front
Tighten
46 support@cedarsummitplay.com
