Cedar Summit F25650 - Attach Heavy T-Bracket to Fort

g pp
Hardware
Step 25: Attach Heavy T-Bracket to Fort
A: Attach Heavy T-Bracket to (044) SW Wall using 2 (WB7) 5/16 x 3” Wafer Bolts (with at washer and t-nut).
(g. 25.1 and 25.2)
2 x 5/16 x 3” Wafer Bolt
 (5/16”atwasher,5/16”t-nut)
Other Parts
1 x Heavy T-Bracket
WB7
Fig. 25.1
Fig. 25.2
044
044
Heavy T-Bracket
5/16” Flat
Washer
5/16” T-Nut
Swing Side Wall
WB7
93 support@cedarsummitplay.com
